Appendix V: Cable Connection Tables
1. Fan Ctrl & Fan PWR Cable
M1809F77A FAN board to S7119 MB
Fan board
Connect to
S7119 M/B
J8
→
J35
J7
→
PE_PW7
J9
→
J10
→
J11
→
2. FP Ctrl Cable
M1718T65-FPB to S7119 MB
M1718T65-FPB
Connect to
S7119 M/B
J4
→
FPIO_1
3. USB Cable
M1717T65-USB to S7119 MB
M1717T65-USB
Connect to
S7119 M/B
J3 & J4
→
USB3_FPIO1
4. VGA & COM port Cable
Front BKT to S7119 MB
Front BKT
Connect to
S7119 M/B
VGA Cable
→
FPIO_VGA2
COM port Cable
→
HD_COM3
