5. HDD BP PWR & Mini-SAS HD Cable (B7119F83V24HR-2T-N)
M1297T65-BP12E-12 to S7119 MB
M1297T65-BP12E-12
Connect to
S7119 M/B
HDD BP PWR Cable-1
PW2 (HDD BP1)
→
D4P_PW1 & PW3
HDD BP PWR Cable-2
PW1 (HDD BP1)
→
D4P_PW2
HDD BP PWR Cable-3
PW2 (HDD BP2)
→
PE_PW16
HDD BP PWR Cable-4
PW1 (HDD BP2)
→
PE_PW5
Mini-SAS HD Cable-1
SATA0_3 (HDD BP1)
→
PCH_SSATA_0123
Mini-SAS HD Cable-2
SATA4_7 (HDD BP1)
→
PCH_SATA_0123
Mini-SAS HD Cable-3
SATA8_11 (HDD BP1)
→
PCH PCH_SATA_4567
6. HDD BP PWR & Mini-SAS HD Cable (B7119F83V12HR-2T-N)
M1297T65-BP12E-12 to S7119 MB
M1297T65-BP12E-12
Connect to
S7119 M/B
HDD BP PWR Cable-1
PW2 (HDD BP1)
→
D4P_PW1 & PW3
HDD BP PWR Cable-2
PW1 (HDD BP1)
→
D4P_PW2
Mini-SAS HD Cable-1
SATA0_3 (HDD BP1)
→
PCH_SSATA_0123
Mini-SAS HD Cable-2
SATA4_7 (HDD BP1)
→
PCH_SATA_0123
Mini-SAS HD Cable-3
SATA8_11 (HDD BP1)
→
PCH PCH_SATA_4567
7. 2x4P PWR Cable
M7119FA77-IO to S7119 MB
M7119FA77-IO
Connect to
S7119 M/B
PW1 2x4P PWR Cable-1
→
PE_PW6
PW2 2x4P PWR Cable-2
→
PE_PW9
PW3 2x4P PWR Cable-3
→
PE_PW8
