3.11.1 Rear IO Board Features
Front View
M7119FA77-RIO Rear IO Board
Specifications
 Rear I/O card for FA77-B7119
 Provide (1) 1G RJ-45 port for IPMI + (2) USB3.0
ports + (1) ID BTN w/ blue LED
 (1) FCI Board to board connector to mainboard
 (1) OCP type-A + (1) OCP type-B connector for NIC
OCP card
