1.4 Standard Parts List
This section describes FT83-B7119 package contents and accessories. Open the
box carefully and ensure that all components are present and undamaged. The
product should arrive packaged as illustrated below.
1.4.1 Box Contents
FT83-B7119 Chassis Kit
 4U chassis*1
 (3+1) 4,800W (80+ Platinum) power Supply
 120X120X38MM FAN*6
 M1718T65-FPB Front Panel Board*1
 M1717T65-USB Front USB Board
 TYAN
®
S7119 Mother Board*1
 M7119FA77-IO PCIE board*1
 M2217-L16-IO OCP riser card*1
 M7119FA77-RIO Rear IO board*1
 M2218-GF16 IO Bridge*1
 M2221-GF24 IO Bridge*1
 M1297T65-BP12E-12*2 (B7119F83V24HR-2T-N SKU) or
 M1297T65-BP12E-12*1 (B7119F83V12HR-2T-N SKU)
 M1809F77A-FB Fan Board*1
 P3280-24i SAS Card
 Mini SAS Cable*3
1.4.2 Accessories
If any items are missing or appear damaged, contract your retailer or browse to
TYAN
®
’s website for service: http://www.tyan.com.
FT83-B7119 Accessory Kit
 CPU heatsink*2
 Rail Kit *1
 Quick Installation Guide *1
 Mounting ear kit *1
 AC Power code (US) *4
 AC Power code (EU) *4
 2*4P GPU Power Cable *10
 Air duct *1
 CPU CLIP *2
 Screw Pack *1
