TYAN FT83-B7119 - Front Panel Board Features

60
http://www.tyan.com
3.6.1 Front Panel Board Features
M1717T65-USB USB Board
Form Factor
 PCB Dimensions: 48.00*19.00*1.6mm
 Thickness: 1.6mm
 Layer: 4 layers
Specifications
 USB 3.0 Connector
 5*2PIN input Connector
