211
8. Oculink Cable
M2221-GF24 to S7119 MB
M2221-GF24
Connect to
S7119 M/B
J1 Oculink Cable-1
→
J8
J2 Oculink Cable-2
→
J9
9. GPU PWR Cable (B7119F83V12HR-2T-N)
S7119 MB to GPU Card
S7119 M/B
Connect to
GPU Card
GPU PWR Cable-1
PE_PW16
→
GPU1
GPU PWR Cable-2
PE_PW13
→
GPU2
GPU PWR Cable-3
PE_PW4
→
GPU3
GPU PWR Cable-4
PE_PW12
→
GPU4
GPU PWR Cable-5
PE_PW15
→
GPU5
GPU PWR Cable-6
PE_PW14
→
GPU6
GPU PWR Cable-7
PE_PW11
→
GPU7
GPU PWR Cable-8
PE_PW17
→
GPU8
GPU PWR Cable-9
PE_PW18
→
GPU9
GPU PWR Cable-10
PE_PW5
→
GPU10
