207
BIOS Temp Sensor
Name Explanation
P0_DTS_Temp
Temperature of the CPU0 Digital Temperature Sensor
P1_DTS_Temp
Temperature of the CPU1 Digital Temperature Sensor
P0_PECI_Value
Temperature of the CPU0 Platform Environment Control Interface
P1_PECI_Value
Temperature of the CPU1 Platform Environment Control Interface
PCH_Temp
Temperature of the PCH
PSU0_Air_Inlet
Temperature of the PSU0 Air Inlet Area
PSU1_Air_Inlet
Temperature of the PSU1 Air Inlet Area
MB_Air_Inet
Temperature of the M/B Air Inlet Area
SYS_Air_Inlet
Temperature of the SYS Air Inlet Area
P0_MOSFET
The Max Temperature of CPU0 MOSFET
P1_MOSFET
The Max Temperature of CPU1 MOSFET
P0_DIMM_MOSFET_1
The Max Temperature of P0 DIMM Area1 MOSFET
P0_DIMM_MOSFET_2
The Max Temperature of P0 DIMM Area2 MOSFET
P1_DIMM_MOSFET_1
The Max Temperature of P1 DIMM Area1 MOSFET
P1_DIMM_MOSFET_2
The Max Temperature of P1 DIMM Area2 MOSFET
P0_MC0_DIM_CH_A
The Max Temperature of P0_MC0_ DIM_ A Slot
P0_MC0_DIM_CH_B
The Max Temperature of P0_MC0_ DIM_ B Slot
P0_MC0_DIM_CH_C
The Max Temperature of P0_MC0_ DIM_ C Slot
P0_MC1_DIM_CH_D
The Max Temperature of P0_MC1_ DIM_ D Slot
P0_MC1_DIM_CH_E
The Max Temperature of P0_MC1_ DIM_ E Slot
P0_MC1_DIM_CH_F
The Max Temperature of P0_MC1_ DIM_ F Slot
P1_MC0_DIM_CH_A
The Max Temperature of P1_MC0_ DIM_ A Slot
P1_MC0_DIM_CH_B
The Max Temperature of P1_MC0_ DIM_ B Slot
P1_MC0_DIM_CH_C
The Max Temperature of P1_MC0_ DIM_ C Slot
P1_MC1_DIM_CH_D
The Max Temperature of P1_MC1_ DIM_ D Slot
P1_MC1_DIM_CH_E
The Max Temperature of P1_MC1_ DIM_ E Slot
P1_MC1_DIM_CH_F
The Max Temperature of P1_MC1_ DIM_ F Slot
GPU0_Core_TEMP
Temperature of GPU0 Core Slot
GPU1_Core0_ TEMP
Temperature of GPU1 Core0 Slot
GPU1_Core1_ TEMP
Temperature of GPU1 Core1 Slot
GPU2_Core_ TEMP
Temperature of GPU2 Core Slot
GPU3_Core0_ TEMP
Temperature of GPU3 Core0 Slot
GPU3_Core1_ TEMP
Temperature of GPU3 Core1 Slot
GPU4_Core_ TEMP
Temperature of GPU4 Core Slot
GPU5_Core0_ TEMP
Temperature of GPU5 Core0 Slot
