Memory Population Table
Single CPU Installed
(CPU0 only)
Quantity of memory installed
1
2
3
4
6
8
12
CPU0_DIMM_A0
√
√
√
√
√
√
√
CPU0_DIMM_A1
√
√
CPU0_DIMM_B0
√
√
√
√
√
√
CPU0_DIMM_B1
√
√
CPU0_DIMM_C0
√
√
√
CPU0_DIMM_C1
√
CPU0_DIMM_D0
√
√
√
√
CPU0_DIMM_D1
√
√
CPU0_DIMM_E0
√
√
√
√
CPU0_DIMM_E1
√
√
CPU0_DIMM_F0
√
√
CPU0_DIMM_F1
√
Dual CPU Installed
(CPU0 and CPU1)
Quantity of memory installed
2
4
6
8
10
12
14
16
18
20
22
24
CPU0_DIMM_A0
√
√
√
√
√
√
√
√
√
√
√
√
CPU0_DIMM_A1
√
√
√
√
√
√
CPU0_DIMM_B0
√
√
√
√
√
√
√
√
√
√
√
CPU0_DIMM_B1
√
√
√
√
√
CPU0_DIMM_C0
√
√
√
√
√
√
√
√
√
√
CPU0_DIMM_C1
√
√
√
√
CPU0_DIMM_D0
√
√
√
√
√
√
√
√
√
CPU0_DIMM_D1
√
√
√
CPU0_DIMM_E0
√
√
√
√
√
√
√
√
CPU0_DIMM_E1
√
√
CPU0_DIMM_F0
√
√
√
√
√
√
√
CPU0_DIMM_F1
√
CPU1_DIMM_A0
√
√
√
√
√
√
√
√
√
√
√
√
CPU1_DIMM_A1
√
√
√
√
√
√
CPU1_DIMM_B0
√
√
√
√
√
√
√
√
√
√
√
CPU1_DIMM_B1
√
√
√
√
√
CPU1_DIMM_C0
√
√
√
√
√
√
√
√
√
√
CPU1_DIMM_C1
√
√
√
√
CPU1_DIMM_D0
√
√
√
√
√
√
√
√
√
CPU1_DIMM_D1
√
√
√
CPU1_DIMM_E0
√
√
√
√
√
√
√
√
CPU1_DIMM_E1
√
√
CPU1_DIMM_F0
√
√
√
√
√
√
√
CPU1_DIMM_F1
√
