Jumpers & Connectors
Connectors
1. COM2 Header (HD_COM2)
19. SATA Connector
(PCH_SATA_0123)
2. Power connector connect to
PCIE BOARD (PE_PW9)
20. SATA Connector
(PCH_SATA_4567)
3. Power connector connect to
PCIE BOARD (PE_PW8)
21. Power connector connect to
PCIE BOARD (PE_PW6)
4. Power connector connect to
GPU Card (PE_PW5)
22. Power connector connect to
GPU Card (PE_PW16)
5. Power connector connect to
GPU Card (PE_PW18)
23. USB Front panel Connector
(USB3_FPIO1)
6. Power connector connect to
GPU Card (PE_PW17)
24. USB TYPEA Connector
(TYPEA_USB3)
7. Power connector connect to
GPU Card (PE_PW11)
25. SSATA SGPIO Connector
(SSATA_SGPIO1)
8. Power connector connect to
GPU Card (PE_PW14)
26. VROC header (J51)
9. ITP Header (XDP1)
27. Power connector connect to
HDD BP (D4P_PW1)
10. CPU0 FAN Header
(CPU0_FAN_1)
28. Power connector connect to
HDD BP (D4P_PW3)
11. TPM and Port 80 Header
(DBG_HD1)
29. Power connector connect to
HDD BP (D4P_PW2)
12. Power connector connect to
GPU Card (PE_PW15)
30. Power connector connect to
HDD BP (PE_PW7)
13. Power connector connect to
GPU Card (PE_PW12)
31. CPU1 FAN Header
(CPU1_FAN_1)
14. Power connector connect to
GPU Card (PE_PW4)
32. IPMB Header (IPMB_HD1)
15. Power connector connect to
GPU Card (PE_PW13)
33. Front panel Connector (FPIO_1)
16. SSATA Connector
(PCH_SSATA_5)
34. Front panel VGA Header
(FPIO_VGA2)
17. SSATA Connector
(PCH_SSATA_4)
35. COM1 Header (HD_COM3)
18. SSATA Connector
(PCH_SSATA_0123)
36. System FAN Connector for
Barebone (J35)
