3.6. Terminal information view
◆ [ENTER]  [4] ◆
In the main menu, press [4] to select “4.Terminal info”, and the following screen
appears, where all the environmental settings are displayed:
Terminal ID=0001
Ver=10.41.00
Application
=Access
Language=ENG
Mode=SN ▼
Press [0] to scroll up and down the screen.
Terminal ID Terminal ID
Version Terminal firmware version
Application Terminal application mode (Access/T&A)
Language Language for text and voice of the LCD screen
Mode Connection mode between terminal and network server
Network type Network connection type (fixed IP/variable IP)
Mac Address Terminal Ethernet hardware address
IP address Terminal IP address
Gateway Terminal Gateway address
Subnet mask Terminal Subnet Mask address
Server IP IP address of network server connected to the terminal
Svr-port Port number of network server program
Card Reader Connected card reader type
FP-Sensor Connected fingerprint sensor type
1:1 Level Identification level for 1:1 authentication
1:N Level Identification level for 1:N authentication
Max User Max. number of users registered to a terminal
Max FP
Max. number of fingerprints registered to a terminal. For
example, if there are 100 registered users and two
fingerprints are registered for each user, then there is a total
of 200 fingerprints registered
All User
Number of current users registered to a terminal including
administrators
All Admin Number of administrators registered to a terminal
All FP Number of fingerprints currently registered to a terminal
