Union Community Virdi 4000 User Guide

VIRDI 4000 User Guide 48
Union Community CO., LTd. 44-3 Hyundai Topics Building 5, 6 floor, Bangi-dong,
Songpa-gu, Seoul, Korea 138-050, Tel: 82-2-6488-3000, Fax: 82-2-6488-3099,
E-Mail:sales@unioncomm.co.kr, http://www.unioncomm.co.kr
authentication records are not deleted.
※ If the settings are initialized, the language of the voice and menus becomes
English. If you need to set other language
(“6. Set Device” “1. System Config”  <Language>: set to 0~4)
Once initialization is done successfully, it moves to the upper menu together
with a “ppiririck” buzzer sound.
3.8.6.2. Authentication record initialization
◆ [ENTER]  [6]  ‘084265’ [ENTER]  [6]  [2] ◆
<Delete All Log>
[ Y=1 / N=2 ] :
To initialize the record, press [1].
If not, press [2].
Deletes all logs related to authentication, but settings and users are not deleted.
Once initialization is done successfully, it moves to the upper menu together
with a “ppiririck” buzzer sound.
3.8.6.3. Factory initialization
<Init Terminal>
[ Y=1 / N=2 ] :
To Factory Default settings, press [1]. If not,
press [2].
Except for the Mac (physical) address stored in the terminal, all settings, users
and log information are deleted for the factory default.
※ If the settings are initialized, the language of the voice and menus becomes
English. If you need to set other language
(“6. Set Device” “5. System Config”  <Language>: set to 0~4)
Once initialization is done successfully, the terminal is rebooted after a “ppiririck”
buzzer sound.
4. How to use the terminal
4.1. Access control
- Menu “3.Option”  “1.Application”  [0] Access control settings
4.1.1. Authentication mode
- Authentication mode display screen

Union Community Virdi 4000 Specifications

General

Brand	Union Community
Model	Virdi 4000
Category	IP Access Controllers
Language	English
