- the same as 4.1.3.
4.2.4. Password authentication
- the same as 4.1.4.
4.2.5. Card authentication
- the same as 4.1.5.
4.2.6. User ID group authentication
- the same as 4.1.6.
4.2.7. Working mode expansion using multi-key authentication
- If more than 5 working modes such as start, leave, outside work, return, and
general are required, it can be expanded up to 41 modes.
- After setting Menu  3.Option  1.Application  [1] T&A, in <Multi Fn-key>,
set more than one key to ‘O’. However, the keys set to ‘X’ are not the case.
- Because a mode is defined with a number key, enter a number key after
entering the function key for authentication. In the server program,
authentication mode is “F3+1”.
- For example, when [F4] is set to [O] and <start time> is set to ‘07:00~09:30’, if
a fingerprint user tries authentication “F4+1”mode,
== 08:34
In the default screen, press [F4].
▼
== F4+0 08:34
The mode is changed to “F4+0”.
Press [1].
▼
== F4+1 08:34
When the mode is changed to “F4+1”, enter the
fingerprint.
▼
== F4+1 08:34
When authentication is successful, a success
message appears.
▼
== START 08:34
The current time is 08:34, so it returns to the start
mode.
