VIRDI 4000 User Guide
53
Union Community CO., LTd. 44-3 Hyundai Topics Building 5, 6 floor, Bangi-dong,
Songpa-gu, Seoul, Korea 138-050, Tel: 82-2-6488-3000, Fax: 82-2-6488-3099,
E-Mail:sales@unioncomm.co.kr, http://www.unioncomm.co.kr
4.1.5. Card authentication
⑤ For a user who is registered as [RF], [RF|FP], or [RF|PW], when placing the
card close to the default screen, a “ppig” buzzer sound will be heard and the
authentication result appears on the LCD.
== 00:00
If you place your card close to the unit, you will hear
a “ppig” buzzer sound.
▼
== 00:00
If authentication is successful, you will see a success
message on the LCD together with the voice
message “You are authorized”. The door relay and
LED turn on.
The default screen appears after 1~2 sec., and the
door relay and LED turn off when the door open
setting time has elapsed.
※
Error message: An error message appears together with the voice message
“Please try again”.
== 00:00
Non-registered card used.
== 00:00
During the authentication request to the
authentication server, network trouble occurred or
the line is disconnected.
For a user who is registered as [RF&FP] or [ID&FP | RF&FP], when placing ▶
the card close to the default screen, a “ppig” buzzer sound will be heard and
the following fingerprint authentication screen appears:
== 00:00
When the light on the fingerprint input window turns
on together with the voice message “Please enter
your fingerprint”, enter your fingerprint and hold it
there until you hear a “ppig” buzzer sound.
▶ For a user who is registered as [RF&PW] or [ID&PW | RF&PW], when
placing the card close to the default screen, a “ppig” buzzer sound will be
heard and the following fingerprint authentication screen appears:
== 00:00
******
A “ppiriririck” buzzer sound will be heard and the
unit waits for the user password to be input. Enter
password and press [ENTER].
