VIRDI 4000 User Guide
49
Union Community CO., LTd. 44-3 Hyundai Topics Building 5, 6 floor, Bangi-dong,
Songpa-gu, Seoul, Korea 138-050, Tel: 82-2-6488-3000, Fax: 82-2-6488-3099,
E-Mail:sales@unioncomm.co.kr, http://www.unioncomm.co.kr
== 00:00
Normal mode; authentication with [ENTER]
==
00:00
F1 mode; authentication with [F1]
==
00:00
F2 mode; authentication with [F2]
== F3 00:00
F3 mode; authentication with [F3]
== F4 00:00
F4 mode; authentication with [F4]
- Fingerprint authentication
Press the function key for authentication with the corresponding mode.
If the function key is not used and authentication is done using Auto Sensing,
the current authentication mode on the screen is used.
- Password authentication
After entering the user ID and changing the authentication mode by pressing
the corresponding function key, enter the password for authentication.
- When a card is used together (i.e., menu “6.Device” settings “3.Card
reader” when <Card Reader> is set to over 1)
When entering the function key, only the authentication mode is changed
instead of entering into fingerprint authentication, so change the
authentication mode by pressing the corresponding function key to enter the
card.
4.1.2. [1:1] fingerprint authentication
⑤ During auto sensing, if the user ID is ‘0001’, enter ‘0001’, and then place your
finger close to the fingerprint sensor. The light on the fingerprint input window
will turn on to detect the fingerprint and the authentication result will be
displayed on the LCD window.
⑤ If the user ID is ‘0001’, enter ‘0001’ and press the function key. The light on
the fingerprint input window will turn on together with voice information. When a
fingerprint is entered, the authentication result will be displayed on the LCD
window.
== 00:00
0001
If the user ID is ‘0001’, enter ‘1’ or ‘0001’ and press
the function key.
▼
