Uponor Smatrix Base User Manual

Controller
CE marking
ERP Base: IV
Base PRO: VIII
Low voltage tests EN 60730-1* and EN 60730-2-1**
EMC (electromagnetic compatibility requirements) tests EN 60730-1
Power supply 230 V AC +10/-15%, 50 Hz or 60 Hz
Internal fuse F3.15AL 250 V, 5x20 3.15A quick acting
Internal fuse, Heat pump output TR5-T 8.5 mm Wickmann 100 mA Time lag
Operating temperature 0 °C to +45 °C
Storage temperature -20 °C to +70 °C
Maximum consumption (Base) 40 W
Maximum consumption (Base PRO) 45 W
Pump and boiler relay outputs 230 V AC +10/-15%, 250 V AC 8 A maximum
General purpose input (GPI) Only dry contact
Heat pump input (Base PRO only) 12 – 24 V DC /5 – 20 mA
Heat pump output (Base PRO only) 5 – 24 V DC /0.5 – 10 mA, current sink ≤ 100 mW
Valve outputs 24 V AC, 0.2 A average, 0.4 A peak
Power connection 1 m cable with europlug (except UK)
Connection terminals for power, pump, GPI and boiler Up to 4.0 mm² solid, or 2.5 mm² flexible with ferrules
Connection terminals for bus communication 0.5 mm² to 2.5 mm²
Connection terminals for valve outputs 0.2 mm² to 1.5 mm²
*) EN 60730-1 Automatic electrical controls for household and similar use
-- Part 1: General requirements
**) EN 60730-2-1 Automatic electrical controls for household and similar use
-- Part 2-1: Particular requirements for electrical controls for electrical
household appliances
***) EN 60730-2-9 Automatic electrical controls for household and similar use
-- Part 2-9: Particular requirements for temperature sensing controls
17.2 Technical specifications
Cables Standard cable length Maximum cable length Wire gauge
Cable from controller to actuator 0.75 m 20 m Controller: 0.2 mm² to 1.5 mm²
External sensor cable to thermostat 5 m 5 m 0.6 mm²
Floor sensor cable to thermostat 5 m 5 m 0.75 mm²
Outdoor sensor cable to thermostat - 5 m Twisted pair
Cable from relay switch to controller
GPI input
2 m 20 m Controller: Up to 4.0 mm² solid, or 2.5 mm²
flexible with ferrules
Relay: 1.0 mm² to 4.0 mm²
Cable to/from heat pump to controller
heat pump input/output (Base PRO
only)
- 30 m Twisted pair
Usable in all Europe
Declaration of conformity:
We hereby declare under our own responsibility that products dealt
with by these instructions satisfy all essential demands linked to the
information stated in the Safety instruction booklet.
UK
CZ
DE
DK
EE
ES
FI
FR
HR
HU
IT
LT
LV
NL
NO
PL
PT
RO
RU
SE
SK
120
UPONOR SMATRIX BASE/BASE PRO · INSTALLATION AND OPERATION MANUAL

Uponor Smatrix Base Specifications

General

Compatibility	Uponor Smatrix thermostats and actuators
Enclosure Rating	IP20
Communication Protocol	Proprietary Uponor Smatrix protocol
Operating Temperature	0°C to +45°C
Storage Temperature	-20°C to +60°C
Relative Humidity	20% to 80% non-condensing
