Mounting Site Review
Review the following items prior to installation and predetermine the solution to any
problems which may exist:
1. Does sufcient space exist for mounting and future servicing of the operator and control box?
2. Which direction will the gate swing?
a. Will the gate operator pull the gate open to the inside (Pull to Open)?
b. Will the gate operator push the gate open to the outside (Push to Open)?
(See Determine Opening Method Section pg 10)
3. Where and how will the actuator mounting brackets be secured to the hinge post and
to the gate? (pgs 11-14)
4. How will the gate bracket be secured to the gate and will additional reinforcement be required?
(pg 11)
5. Where will the control box be mounted to support the weight of the battery and other components
and can it be located within 8 feet to prevent splicing of the linear actuator cable? (pg 20)
6. For AC Charged System - How far away is the 120 VAC receptacle for the transformer?
Transformer is supplied with 12 feet of cable. If extension is needed use power source cable
Extension Kit part #630038. See Power Source Cable Extension chart for identifying the wire
size needed for the distance required. Transformer must be installed indoors or in a raintight
enclosure. Transformer should not be exposed to moisture. (pg 24)
7. For Solar Charged System - Where will the solar panel mount so that optimum sunlight is
received? Solar panel is provided with 15 feet of cable, If extension is needed use power source
cable Extension Kit part #630038 or 75’ Solar Extension part #520016. See Power Source
Cable Extension chart for identifying the wire size needed for the distance required. Solar panel
typically needs to be facing a South or Southwest direction. (pg 25)
8. How will accessory control wiring, if any, be brought to the control box? Knock outs are provided
in control box bottom for conduit. (pg 20)
9. Have all safety concerns been addressed? See Safety Section pg 3 and Entrapment Zones on
pg 39 for more information.
