Patriot Control Board Information
The Patriot control board is capable of operating two gates. If your installation is a single gate you
can operate the gate on the Gate 1 or Gate 2 connector. Set control switch “ON” for the connector
being used.
18
Patriot Control Board
Obstruction
Reverse
Sensitivity
Adjustments
Timer to Close
Delay Adjustment
DS1 Function
Dip Switches
LED Indicator
Button
System Reset
Open / Close
Command
J2 Terminal Entrapment Siren Electronic or Mag
Lock Output
Photo Eye Power
or Security Shunt
DS2 Function
Dip Switches
Gate 2 Plug
Gate 1 Plug
15 Amp Fuse
Gate 1
15 Amp Fuse
Gate 2
