7
GATE QUALIFICATIONS/APPLICATIONS
This gate operator is rated for vehicular class I, II, III, or IV swing gates up to 16 feet in length and
up to 650 pounds in weight, as dened by UL-325. If your gate exceeds either one of these limits,
please consult a qualied technician or the factory for application questions and advice.
(Example: Convert one 20’ gate into two 10’ gates and use a dual gate operator.)
Note: The total gate opening normally cannot exceed 120 degrees.
Consult a service technician or the factory if greater opening is required.
The Patriot Gate Operator is recommended for Gates that meet the following descriptions:
Ornamental Iron
16 feet max length
Max weight 650 lbs.
Ranch Gate
16 feet max length
Max weight 650 lbs.
Farm Gate
20 feet max length
Max weight 300 lbs.
Chain Link Gate
16 feet max length
Max weight 650 lbs.
PREPARATION AND OVERVIEW
