6
• SAE Standard wrenches & sockets • Welder
• Nut driver • Drill and bits
• Level and tape measure • Drill adapter for socket attachment
• Pliers • Hack saw
• Wire Cutters/Strippers
Welding is the recommended method of securing the linear actuator mounts to the gate and hinge
post. Bolt on brackets require frequent service to keep tight. They must be very securely attached
(i.e. carriage bolts with lock nuts and washers). Lag type bolts are not recommended. Loose or
unstable linear actuator mounts will result in improper operation.
IMPORTANT CAUTIONS:
A. Do not perform any welding with the actuator cable plugged into the control board or the battery
connected. Serious damage to the control board and/or battery may occur if attempted.
B. Do not attempt to hold control box and drill mounting holes with components installed. This
could damage the components.
C. Always disconnect the battery power from the control board using the quick connect harness
prior to wiring any devices to the control board.
D. Do not test or operate without actuator securely attatched to the gate. Serious damage to the
actuator limit switch assembly may occur if attempted.
GENERAL TOOL REQUIREMENTS
