Instructions for Soft Stop Set Up on New Installations
Instructions for Soft Stop Set Up on Existing Installations
Soft stop setup for retract and extend on new installation only.
1. Disconnect the linear actuator from the gate.
2. Rotate the extension screw counter-clockwise (turn to left) 6 complete rotations.
3. Reconnect the linear actuator to the gate.
4. The gate should now be about 18” from the fully open position.
5. Turn on the DS1 switch 6 and 7 ON at this time.
Soft stop setup for extend on new installation only.
1. Turn on the DS1 switch 7 ON at this time.
Soft stop setup for retract on new installation only.
1. Disconnect the linear actuator from the gate.
2. Rotate the extension screw counter-clockwise (turn to left) 6 complete rotations.
3. Reconnect the linear actuator to the gate.
4. The gate should now be about 18” from the fully open position.
5. Turn on the DS1 switch 6 ON at this time.
Soft stop setup for retract and extend on existing installation only.
1. Adjust retract and extend limit switches so that the gate is stopping about 24” short of the
desired retracted and extended stop position.
2. Turn on the DS1 switch 6 and 7 ON at this time.
3. Operate the gate and verify soft stop feature was activated.
4. Adjust retract and extend limit switches to the desired nal stop position.
Soft stop setup for extend on existing installation only.
1. Adjust extend limit switch so that the gate is stopping about 24” short of the desired
extended stop position.
2. Turn on the DS1 switch 7 ON at this time.
3. Operate the gate and verify soft stop feature was activated.
4. Adjust extend limit switch to the desired nal stop position.
Soft stop setup for retract on existing installation only.
1. Adjust retract limit switch so that the gate is stopping about 24” short of the desired
retracted stop position.
2. Turn on the DS1 switch 6 ON at this time.
3. Operate the gate and verify soft stop feature was activated.
4. Adjust retract limit switch to the desired nal stop position.
