57
9. Transmitter will not
operate the gate.
(LCR radio equipment
only)
1. Open the control box and locate the Patriot control board. Locate the
“LED Indicator” push button and the “Push Button Input” LED. Push
and hold the “LED indicator” push button, then press the transmitter
button and observe the “Push Button Input” LED. The LED should
come on while the transmitter button is depressed.
2. If the “Push Button Input” LED did not come on in step 1 then make
sure that the green J2 connector on the control board is securely
connected, replace the battery in the transmitter and verify that the
transmitter is programmed to operate the receiver (refer to page 14
“programming receiver and transmitter”).
3. If the “Push Button Input” LED in step 1 did come on and the gate
did not operate then locate the “Open/Close Command” button
located at the bottom center of the Patriot control board. Press the
“Open/Close Command” button and note gate operation.
4. If the gate did not operate in step 3, verify the 15-amp fuse on the
Patriot control board adjacent to the actuator plug being used is not
blown, (a fuse can be blown and look good) replacing is the best
way to verify fuse is good.
5. If the gate did not operate in step 3 and the fuse was good in step 4,
most likely a safety accessory connected to the green J2 connector
is active. Verify this by depressing the “LED Indicator” push button
and observe the LED’s located in the lower left corner of the Patriot
control board. If an LED is on, identify the accessory connected to
the corresponding J2 connector pin and correct the problem.
6. Other possibilities are: both the open and close limit LED’s are on
at the same time, adjust limit switches. Control board is defective or
battery could be too weak to operate the gate. Please call the factory
for help identifying the cause.
