2GM
2-3-5
Connector Pin No. Signal I/O Description
YC3
Connected
to the
parallel I/F
YC4
Connected
to the USB
YC5
Connected
to the
Ethernet
YC6
Connected
to the
scanner
PWB
12 PE O Paper empty signal
13 SEL O Select signal
14 CAN I CAN signal
15 RMR - Not used
16 SG - Ground
17 FG - Ground
18 INIT O 5 V DC power supply
19 GND - Ground
20 GND - Ground
21 GND - Ground
22 GND - Ground
23 GND - Ground
24 GND - Ground
25 GND - Ground
26 GND - Ground
27 GND - Ground
28 GND - Ground
29 GND - Ground
30 ARARM - Ground
31 ASFON - Not used
32 FAULT O FAULT signal
33 HSTI - Not used
34 EXPRM - Not used
35 PRDY O Power ready signal
36 SELI - Not used
1 VBUS I VBUS signal
2 DATA- O DATA- signal
3 DATA+ O DATA+ signal
4 GND - Ground
1 TXOP O TXOP signal
2 +3.3 V O 3.3 V DC power supply
3 TXON O TXON signal
4 RXIP I RXIP signal
5 +3.3 V O 3.3 V DC power supply
6 RXIN I RXIN signal
7 NC - Not used
8 GND - Ground
9 +3.3 V O 3.3 V DC power supply
10 /LEDL I LEDL signal
11 +3.3 V O 3.3 V DC power supply
12 LEDN I LEDN signal
1 SHRGB O RGB shift signal
2 SW O Color/monochro control signal
3 SWN O Color/monochro control signal
4 CCDCLKN O CCD clock signal
5 GND - Ground
6 CCDCLK O CCD clock signal
7 GND - Ground
8 RSN O CCD RS signal
9 GND - Ground
10 CPN O CCD CP signal
11 GND - Ground
12 SH O CCD shift signal
13 GND - Ground
14 GND - Ground
15 GND - Ground
16 CCDG(O) I Image data G (green) signal (analog)
17 GND - Ground
18 CCDB(E) I Image data B (blue) signal (analog)
To Next Page
