2GM
2-3-6
Connector Pin No. Signal I/O Description
YC6
Connected
to the
scanner
PWB
YC7
Connected
to the
engine
PWB
YC8
Connected
to the laser
scanner
unit
YC10
Connected
to the
debugger
I/F
YC13
Connected
to the
scanner
PWB
19 GND - Ground
20 CCDR I Image data R (red) signal (analog)
1 SGND - Ground
2 SGND - Ground
3 +3.3 V I 3.3 V DC power supply
4 +3.3 V I 3.3 V DC power supply
5 +5 V I 5 V DC power supply
6 OUTPEN I OUTPEN signal
7 SGND - Ground
8 PLGCLK O PLGCLK signal
9 EGSO I EGSO signal
10 SCKN O SCKN signal
11 EGSI O EGSI signal
12 PDMASKN I PDMASKN signal
13 SBSY I SBSY signal
14 SDIR I SDIR signal
15 EGRN I EGRN signal
16 SGND - Ground
17 RSTN I RSTN signal
18 SGND - Ground
19 OVSYNC I OVSYNC signal
20 SGND - Ground
1 SGND - Ground
2 SAMPLEN O SAMPLEN signal
3 VDATA O VDATA signal
4 OUTPEN O OUTPEN signal
5 SGND - Ground
6 +5 V O 5 V DC power supply
7 SGND - Ground
8 PDN I Horizontal synchronization signal
1 +5 V O 5 V DC power supply
2 DBTXD O DBTXD signal
3 DBRXD I DBRXD signal
4 DBCLK I DBCLK signal
5 GND - Ground
1 SGND - Ground
2 AUDIO O AUDIO signal
3 +5 V O 5 V DC power supply
4 FPRSTN O FPRSTN signal
5 PANTXD O PANTXD signal
6 PANRXD I PANRXD signal
7 PANRTS O PANRTS signal
8 PANCTS I PANCTS signal
9 +3.3 V O 3.3 V DC power supply
