1-3-6
2GM
Remove the pin holding scanner unit.
1. Remove the yellow pin for scanner unit and the
paper tag from the left side of the machine.
Pin
Paper tag
Figure 1-3-8
1. Open the front top cover and front cover.
2. Store the pin for scanner unit on the inside of the
front cover as shown in the illustration.
* Be sure to save this pin as it is essential that it be
used whenever the machine is moved. The
location for storing the pin is clearly marked on
the right side of the inside portion of the front
cover.
Install a toner container.
Front top cover
Front cover
Figure 1-3-9
Pin
Figure 1-3-10
