1-3-7
2GM
3. Remove the process unit from the machine.
CAUTIONS
• Place the process unit on a clean, level surface.
• Never expose the process unit to any sort of impact
or shock.
• The drum in the process unit is sensitive to light.
Never expose the drum even to normal office
lighting (500 lux) for more than five minutes.
4. Remove the protective cardboard.
5. Move the lock lever until it is in its unlocked
position (marked UNLOCK).
Figure 1-3-11
Figure 1-3-13
Figure 1-3-12
Process unit
Protective
cardboard
To Next Page
