1-3-8
2GM
6. Shake the toner container horizontally back and
forth five or six times so that the toner inside of it
becomes evenly distributed.
7. Remove the orange protective seal.
8. Align the knob on the left side of the container
with the groove in the process unit and set the
toner container into the process unit.
Figure 1-3-14
Figure 1-3-16
Figure 1-3-15
Toner container
Seal
Process unit
Knob
Toner container
