Utax CD 1018

1-3-9
2GM
9. Hold the process unit stable and push on the
areas marked PUSH HERE on the toner
container until the container clicks into place.
10. Push the lock lever back into its locked position.
11. Set the process unit into the machine by aligning
the pins on both sides of the process unit with the
guides inside the machine, and then slide the
process unit all the way back into the machine
until it stops.
Figure 1-3-17
Figure 1-3-19
Figure 1-3-18
Toner container
Lock lever
Pin
Pin
