PARAMETER VALUE DESCRIPTION DEFAULT MEMO
Fot1
Photocell 1 input
Thismenuallowsenablingtheinputfortype1photocells,thatistosay,
photocellsactivebothduringtheopeningandclosingphase
no
no
Inputdisabled.Nojumperwiththecommonisrequired
AP.Ch
Input enabled
Fot2
Photocell 2 input
Thismenuallowsenablingtheinputfortype2photocells,thatistosay,
photocellsnonactiveduringtheopeningphase
CFCh
CFCh
Inputenabledevenatstandstillgatetoo
no
Inputdisabled.Nojumperwiththecommonisrequired
Ch
Inputenabledfortheclosingphaseonly
WARNING: if you select this option, you must disable photocell test
Ft.tE
Test of the photocells
Inordertoachieveasaferoperationfortheuser,theunitperformsa
photocellsoperationaltest,beforeanormalworkingcycle.
Ifnooperationalfaultsarefound,thegatestartsmoving.
Otherwise,itwillstandstillandtheashinglightwillstayonfor5sec.
Thewholetestcyclelastslessthanonesecond
no
no
Function deactivated
Si
Function activated
CoS1
Safety ribbon 1 input
Thismenuallowsenablingtheinputfortype1safetyribbon,thatistosay,
xed ribbons
no
no
Input disabled
AP
Inputenabledduringtheopeninganddisabledduringtheclosure
APCh
Inputenabledinopeningandclosure
CoS2
Safety ribbon 2 input
Thismenuallowsenablingtheinputfortype2safetyribbon,thatistosay
mobile ribbons
no
no
Input disabled
Ch
Inputenabledduringtheclosinganddisabledduringtheopening
APCh
Inputenabledinopeningandclosure
Co.tE
Test of the safety edges
Thismenuallowssettingthemethodofcontrolofthesafetyedges
working.
no
no
Test disabled
Foto
Testenabledforopticalsafetyedges
rESi
Testenabledforconductiverubbersafetyedges
FC.En
End of Stroke Inputs
no
no
Endofstrokeinputsaredisabled
L.SW
Endofstrokeequippedwithanormallycloseswitch
Cor.0
Endofstrokeinseriesofmotorwinding
EnCo
Encoder Input
no
no
Input disabled
Si
Input enabled
