Property Specification
External loads:
Current outputs R
L
< 500 Ω
0 … 1 V output R
L
> 2 kΩ
0 … 5 V and 0 … 10 V outputs R
L
> 10 kΩ
Max. wire size
2.5 mm
2
(14 AWG)
Accuracy of analog outputs at +20 °C ±0.05 % full scale
Temperature dependence ±0.005 % / °C full scale
Relay outputs
Number and type of relays 2 pcs, SPDT
Max. switching power, current, voltage 30 W, 1 A, 40 VDC / 28 VAC
Max. wire size in PELV version
2.5 mm
2
(14 AWG)
Max. wire size in AC (mains) version
1.5 mm
2
(16 AWG)
Ethernet interface
Supported standards 10BASE-T, 100BASE-TX
Connector 8P8C (RJ45)
Supported protocols Modbus TCP/IP (port 502), HTTPS (port 8443)
1) The power supply option is selected when ordering the transmitter.
Table 14 Compliance
Property Specification
Safety standard IEC/UL/EN 61010-1
EMC compliance EN 61326-1, Industrial Environment
FCC compliance FCC Part 15 Compliance Statement for Class B
Unintentional Radiators
Table 15 Mechanical specifications
Property Specification
Housing classification IP66, NEMA 4, IK08, DIN EN ISO 11997-1: Cycle B
Housing material AlSi10Mg (DIN 1725)
Display window material Chemically strengthened glass (IK08)
Weight 1.5 kg (3.3 lbs)
Chapter 10 – Technical data
71
