Property Description/Value
Selectable current output types 4 … 20 mA, 0 … 20 mA, scalable
Max. wire size
2.5 mm
2
(14 AWG)
Accuracy of analog outputs at +20 °C (+68 °F) ±0.05 % full scale
Temperature dependence ±0.005 % / °C full scale
External loads:
Current outputs R
L
< 500 Ω
0 … 1 V output R
L
> 2 kΩ
0 … 5 V and 0 … 10 V outputs R
L
> 10 kΩ
Indigo520 relay outputs
Number and type of relays 2 pcs, SPDT
Max. switching power, current, voltage 30 W, 1 A, 40 V DC / 28 V AC
Max. wire size in PELV version
2.5 mm
2
(14 AWG)
Max. wire size in AC (mains) version
1.5 mm
2
(16 AWG)
Ethernet interface
Supported standards 10BASE-T, 100BASE-TX
Connector 8P8C (RJ45)
Supported protocols Modbus TCP/IP (port 502), HTTPS (port 8443)
1) The power supply option is selected when ordering the transmitter.
Table 3 Compliance
Property Description/Value
Indigo520 EU directives EMC Directive (2014/30/EU)
Low Voltage Directive (2014/35/EU)
RoHS Directive (2011/65/EU) amended by
2015/863
Indigo510 EU directives EMC Directive (2014/30/EU)
RoHS Directive (2011/65/EU) amended by
2015/863
EMC compatibility IEC/EN 61326-1, industrial environment
CISPR 32 / EN 55032, Class B
Electrical safety IEC/EN 61010-1
Indigo520 compliance marks CE, China RoHS, FCC, RCM
Indigo510 compliance marks CE, China RoHS, FCC, RCM, UKCA
Listing marks Canada (SGS), US (SGS)
