Property Description/Value
FCC compliance FCC Part 15, Class B
Table 4 Mechanical specifications
Property Description/Value
NEMA rating NEMA 4: Hose down and splashing water, NEMA
250-2014 Type 4
Housing classification IK08, DIN EN ISO 11997-1: Cycle B (VDA 621-415)
Housing material AlSi10Mg (DIN 1725)
Display window material Strengthened glass (IK08)
Weight 1.5 kg (3.3 lb)
Dimensions (H × W × D) 142 × 182 × 67 mm (5.63 × 7.17 × 2.64 in)
Cable diameters for cable glands
M20×1.5 glands 5.0 … 8.0 mm (0.20 … 0.31 in)
M20×1.5 glands with split bushing 7 mm (0.28 in)
M16×1.5 glands 2.0 … 6.0 mm (0.08 … 0.24 in)
Do not modify the unit or use it in ways not described in the
documentation. Improper modification or use may lead to safety hazards,
equipment damage, failure to perform according to specification, decreased
equipment lifetime, or the warranty becoming void.
CAUTION!
Do not use the transmitter in a manner not specified by Vaisala. If
the transmitter is used in an unspecified manner, the protection provided by the
equipment may be impaired.
CAUTION!
9
