Figure 3 Parts of Wall Mounted Models (HMW82/82P100/83
and TMW82/83)
1
=
Opening tab: push down to open the transmitter.
2
=
Direction arrow. Must point up after mounting base has been
installed on the wall.
3
=
Wiring label.
4
=
Screw terminals.
5
=
Mounting base.
6
=
Transmitter cover with component board.
2
1
3
4
6
5
