VAMP Ltd Arc protection system
User manual
VAMP 220 / 220R
VM220.EN004 Vamp 24h support phone : +358 (0)40 573 6316
43
VA
ADDR.
1 2 3 4 5 6
ON
VAM
Figure 6.3-1 DIP switches of the slave unit.
8
1
ON
13
16
2
18
4
ON
ON
123456
123456
ON
Figure 6.3-2 Examples of address settings (address 13 and 18 respectively).
6.4. System configuration
After the sensors have been wired, and the slaves have been
given addresses, the system configuration is to be read into the
memory of the master unit. Do as follows:
Choose INSTALL mode using the up and down push-buttons.
Activate the mode with the S push-button. The display starts to
flash.
Start reading the system configuration by pressing the E push-
button.
