10. Ordering code VAMP220/220R
VAMP 220
-3
Nominal Current [A]
3 = 1A / 5A
Trip 3 operation time [ms]
A
=FAST
B =80ms
C =100ms
D =150ms
Trip 4 operation
3 =Normal
4 = Trip 4 -> CBFP
Supply Voltage [V]
A
= 40.. 265Vac/dc
B = 18.. 36Vdc
Optional Hardware 1
A
= None
B
= T1 & T2 relays NC, T3 & T4 relays NO
Optional Hardware 2
A
=None
B
= B I/O Option Card
Accessories :
Order Code
Explanation Note
VAM 12 CD Slave Unit (VAMP220) 10 Sensor Inputs
VAR 4 CE 4/0 Trip Multiplier Relay 1xNO -> 4xNO
VAX 2 CB Interface Unit ( use vx002 cable ) For Sensor Cable Extension
VA 1 DA-6 Arc Sensor Cable length 6m
VA 1 DA-20s Arc Sensor Cable length 20m (Shielded)
VA 1 DT-6 Temperature Sensor Cable length 6m
VA 1 DP-5 Portable Arc Sensor Cable length 5m
VX001-xx Modular Cable VAM <-> VAM ( xx = Cable length [m] ) Note 1. Preferred Cable Lenghts
VX002-xx Shielded Sensor Cable ( xx = Cable Length [m] ) Example: JAMAK
VX010-xx Modular Cable VAMP <-> VAM ( xx = Cable length [m] ) Note 1. Preferred Cable Lenghts
VYX001 Surface Mounting Plate for Sensors L-shaped
VYX002
Surface Mounting Plate for Sensors Z-shaped
VYX076 Raising Frame Height 40mm
VYX077 Raising Frame Height 60mm
VA 1 EH-6 Arc Sensor (Pipe type) Cable length 6m
