RAPTOR Hydro
Position: Number: Description:
On the cross-bar of the handlebars by the
control lever on the right handle
1
Machine travel start:
0 = machine is not moving; 1 = machine is moving
Upper control lever on the right handle 2
Starting the working tool drive:
0 = the work tool is stopped (not working); 1 = safety lock engaged; 2 = work tool is
rotating
On the cross-bar of the handlebars by the
control lever on the left handle
3
Service brake:
0 = machine is moving; 1 = brake activated
Combined sticker, which is attached under the
rear plastic cover on the device frame
4 Caution - Before using the device, read through the operating instructions.
5 Caution - When doing maintenance on the machine, disconnect the spark plug connector.
6
Risk of being hit by flying debris, cuttings, ejected items, etc. Other persons and animals -
keep a safe distance from the machine.
7 Danger of squeezing or impact - keep a safe distance.
8 During work, observe the maximum permissible slope for operation.
60
9 Use eye and hearing protection.
10
Bypass control: the lever on the left - manual travel, the lever on the right - only motorized
travel is possible.
The sticker on the air filter cover on the left
side of the engine.
11 Recommended fuel.
12 Caution ā Risk of fire
Table 31: Safety Pictograms
3.3 Basic Information
3.3.1 Use of the Machine
The RAPTOR Hydro multifunctional carrier is intended to provide drive (while at the same time ensuring the movement of the whole
assembly) for various work tools that can be attached to the front or the rear of the machine. The attached tools may be propelled by the
engine through the clutch that can be disengaged and that has got the integrated brake, or pushed or towed.
Name Type Ordering
No.
Description Active Passive
Mulcher RMS-600 4471
The work tool for cutting scraggly grass, including self-seeded trees up to the diameter of 1.5
cm.
X
Drum lawn mower RBS-700 4472 The attachable work tool for cutting maintained meadow-like grassy areas. X
Hay tedder ROP-115 4477
The tool is intended for hay tedding and raking of the cut grass into rows on grassy meadow-
like areas.
X
Dozer blade RSR-1000 4478 The attachment for removing freshly fallen snow. X
Sulky (the carriage
with the seat)
AV-650 4217
The attachable adapter with the seat for the operator (the sulky) that can be used in
conjunction with tools attached to the front of the machine.
X
The single-axle
trailer
ANV-200 4475 The trailer serves for transporting attachable adapters or various material. X
Wheel weight - 4473
The weight serving to increase adhesion of the carrier when travelling with the single-axle
trailer and during the work with adapters in difficult conditions.
X
Snow chains - 4476 Intended to improve adhesion on snow; suitable for the tools for winter maintenance X
Table 32: Attachments
61
ļ The use for purposes other than the intended purpose is; therefore, to be considered a use for an unspecified
purpose!
60
The maximum slope value applies to all directions. The final value is always reduced, when compared to the real measured value, by employing the safety coefficient.
61
All the attachments specified in the chart are not part of the RAPTOR Hydro product. They are separate products. Contact your dealer or visit the web pages of the manufacturer
www.vari.cz or our facebook profile at https://www.facebook.com/VARIcz/ for the information on the dates of introducing individual attachments to the market.
42
revize 11/2017
