Service Mode
Plan of the mode
Button Function Button Function
Diagnosis
Real-time
measurements
Access to the real-time
measurement sub-menu
Probes
Measurements of temperature
sensors
Sensors
State of sensors and actuators
(limit switches, potentiometers,
solenoid valves)
Pressure
All measures necessary to trou-
bleshoot the pressure mode
Running time
Access to the component oper-
ating time menu
Components
Motors
Solenoid valves
Valves for pan lling, steam
destroyer and circuit pressure
Cooking modes
Usage time of different cooking
modes
Heating
Heating zones and hob
Service message
statistics
List of all messages from ser-
vices, with times
Service message
history
List of the last 15 messages
with full details of the unit at the
time of the message
Service message
history
Details
Status of the unit (sensors,
probes and actuators) at the
time of the service message
Diagnosis
Button for navigating between
the service mode and user mode
For more information on the user menus refer to the user manual.
A full description of the service mode is available in the service mode chapter.
IV.04
v03 • July-2016 • Hen
Service Mode Module
Line Units Serial number (starting from) Sw Revision
VCCM
VCCWE
All ExxXH1009xxxxxxx 01-00-08
