Description of the Service Mode
Diagnosis, probes
Columns displayed
Column Explanation Details
Temp.
Temperature in real time. Is displayed
in red if the value exceeds the
tolerance.
●Displays Err. if the thermocouple is faulty or un-
plugged.
● Displays - 30°C (-22°F) if no allocation memorised.
Offset/Calib.
Offset values calculated during the
last calibration.
●B4 à B17 =
[200 - 6000] without unit, since soft 01-01-01.3
[500 - 6000] without unit, before soft 01-01-01.3
●B12-1 > B13-6 = [-3 ; +3] °C
●B1 or B2 = [-3 ; +7] °C
Max. Temp.
Maximum temperature reached. Is
displayed in red if it exceeds the
tolerance value.
Tolerance
Maximum acceptable value
Date
Date of recording the last maximum
value reached.
IV.07
v03 • July-2016 • Hen
Service Mode Module
Line Units Serial number (starting from) Sw Revision
VCCM
VCCWE
All ExxXH1009xxxxxxx 01-00-08
