USB
Service data: Description
Description of the content of the service le
Diagnostic section, "Diag 2"
This contains information from the service pack about real-time sensor measurements.
For more information on the sensors see the "components" chapter.
Field name Translation Note
Sensor / Actor Sensor / actuator concerned
State / Value Actual value 0 ... Max. Tol.
Max. Maximum value reached Yes / no
Unit Temperature measurement unit C° / F°
Max. Date / Time Date and time when the maximum
value was reached
Offset/Calib. Offset value obtained during the last
calibration
Min. Tol. / Max. Tol. Min.-Max. tolerance
Diagnostic section, "Diag 3"
This contains information from the service pack about real-time measurements.
For more information on the sensors see the "components" chapter.
Field name Translation Note
Sensor / Actor Sensor / actuator Internal use
Date / Time Date and time of recording
Operating time section, RT1
This contains information from the service pack about component use statistics.
For more information on the sensors see the "components" chapter.
Field name Translation Note
Sensor Sensor concerned
Actual cycles Number of cycles since the last reset
Actual (Min.) The number of minutes since the
last reset
Yes / no
Total cycles Total number of cycles since
commissioning
These values may be not to date
if the main board and SD card are
swapped out.
Total (Min.) Total number of minutes since com-
missioning
These values may be not to date
if the main board and SD card are
swapped out.
v03 • July-2016 • Hen
V.09
Communication Module
Line Units Serial number (starting from) Sw Revision
VCCM
VCCWE
All ExxXH1009xxxxxxx 01-00-10
