10. Technical Specifications
128 Green X / X18 (Model: PHT-75CHS) Installation Manual
Dimensions (unit: mm / inch)
Model
Item
Description
Green X
Total Height
Without
Base
Max. 1520.6 mm (59.8”)
With
Base
Max. 1545.4 mm (60.8”)
Dimensions
during
operation
(Length x Width x
height)
Without
CEPH
Without Base:
1458 (L) x 1085 (W) x 1520.6 (H) (mm)
57.4 (L) x 42.7 (W) x 59.8 (H) (”)
With Base:
1458 (L) x 1085 (W) x 1545.4 (H) (mm)
57.4 (L) x 42.7 (W) x 60.8 (H) (”)
With
CEPH
Without Base:
1458 (L) x 1906 (W) x 1520.6 (H) (mm)
57.4 (L) x 75.0 (W) x 59.8 (H) (”)
With Base:
1458 (L) x 1906 (W) x 1545.4 (H) (mm)
57.4 (L) x 75.0 (W) x 60.8 (H) (”)
Rotating Unit Vertical
Movement
Max. 800 mm (31.50”)
Installation type
Base Stand / Wall Mount
(Default: Wall Mount type)
Packing Box Organization
Main Box, CEPH Box (Optional), Base Box
(Optional)
Green X18
Total Height
Without
Base
Max. 2315.4 mm (91.16”)
With
Base
Max. 2345.4 mm (92.34”)
Dimensions
during
operation
(Length x Width x
height)
Without
CEPH
Without Base:
1085.0(L) x 1343.5(W) x 2315.4(H) (mm)
42.72(L) x 52.89 (W) x 91.16(H) (”)
With Base:
1085.0(L) x 1343.5(W) x 2345.4(H) (mm)
42.72(L) x 52.89 (W) x 92.34(H) (”)
With
CEPH
Without Base:
1905.5(L) x 1374.9 (W) x 2315.4(H) (mm)
75.02(L) x 54.13 (W) x 91.16(H) (”)
With Base:
1905.5(L) x 1374.9 (W) x 2345.4 (H) (mm)
75.02(L) x 54.13 (W) x 92.34(H) (”)
Rotating Unit Vertical
Movement
Max. 800 mm (31.50”)
Installation type
Base Stand/Wall Mount
(Default: Wall Mount type)
Packing Box Organization
Main Box, CEPH Box (Optional) Base Box
(Optional)
