1. Introduction
Green X / X18
(Model: PHT-75CHS) Installation Manual 7
1.4 Marks and Symbols
Symbols Description Location
Dangerous voltage
Power board
/ Inverter
board /
Monoblock
Protective earth (Ground) Column
Off (power: disconnected to the
Main Power Switch)
Main Power
Switch
On (power: connected to the Main
Power Switch)
Main Power
Switch
Alternate current Label
Type B Applied Equipment
(IEC 60601-1: Degree of protection
against leakage current and electric
shock: Class 1 equipment)
Label
Radiation hazard Label
Authorized European
Representative name and address
Label
The CE symbol indicates that this
product complies with the
European Directive for Medical
Devices 93/42/EEC as amended by
2007/47/EC as a class IIb device.
Label
Warns ESD hazard.
MCU board /
Board
package
