2. Pre-Installation Requirement
Green X / X18 (Model: PHT-75CHS) Installation Manual 23
English
2.6 Installing the Warning Lamp and Door Interlock Switch
Refer to Appendix A for a complete installation guide.
 This system can be equipped with a warning lamp and the door interlock
switch, activated when the X-ray is energized.
 The warning lamp and door interlock switch are not included with the
equipment.
 The warning lamp and the door interlock switch must be installed by a
qualified technician.
2.7 Installing the Emergency Stop Switch
Refer to Appendix B for a complete installation guide.
 Install the emergency stop switch along with the main power cable in the
central distribution panel.
 Install this switch within easy reach of the operator but cannot be
accidentally pressed.
 The switch must be a fool-proof model.
