3. Before the Installation
Green X / X18 (Model: PHT-75CHS) Installation Manual 31
English
3.4 Transporting the X-ray Unit
To transport the X-ray Unit:
At a minimum, three persons are required to lift and
carry the X-ray unit.
1. Tape the column to attach it to the foam.
2. Grab the handles and lift the X-ray unit (main unit) from the pallet.
3. Place the X-ray unit with EPS (Main Base) on a transport dolly and carry
the unit to the installation site.
 When putting the Main Unit on the dolly, ensure that
the center of the mass indicator is aligned with the
center of the dolly.
 If you move the unit manually, ensure that the
person holding the upper handle takes the lead.
