4
.
Install
ing the X
-
ray Unit: B
ase Stand Type
Green
X
/
X1
8
(
Model:
PHT
-
75CHS)
Installa
tion
Manua
l
55
E
nglish
4.4
Fixing th
e Base
4.4.1
Concrete Floor
T
o fix the
base on the
concrete flo
or:
Required T
ool
Hammer
Dril
l
L
=
200 mm
(7+-.9”)
Ratchet
Wrenc
h
T
ips: 3
mm
- 8
mm
(
0.12”
-
0.3”
)
Hammer
N/A
Parts and
Accessory
Anchor Bolt
5/16 x 60 w
/ Spring
and
Flat
Washers
-
2 pcs
(Part No. 34)
Spring wash
er
M8
-
2 pcs
1.
Mark th
e base’
s location on t
he floor
.
62
64
