4. Installing the X-ray Unit: Base Stand Type
56 Green X / X18 (Model: PHT-75CHS) Installation Manual
2. Drill holes on the floor. Each hole must be 12 mm x 13 mm in depth.
3. Remove the debris and clean the holes using the dust pump.
4. Secure the anchor bolts with the hammer.
5. Place the base. Put nuts and washers on the anchor bolts and tighten them
with a ratchet wrench to secure the base.
