2. Pre-Installation Requirement
Green X / X18
(Model: PHT-75CHS) Installation Manual 11
English
Minimum Space Required
Without CEPH unit 2,500 mm (L) x 1,700 mm (W) x 2,700 mm (H)
With CEPH unit 2,500 mm (L) x 2,500 mm (W) x 2,700 mm (H)
If the ceiling height is less than 2318 mm (without Base) /
2346 mm (with Base) (= max. height of the column + 100
mm), refer to Appendix C. Limiting the Column Height
to
lower the max. The height of the column.
Lead Thickness
1 mm
The width of the Entrance
The X-ray room door must have a clearance of more than 800 mm (31.5”) wide.
Floor Area
The floor of the X-ray room must be stable and level for system balance.
The floor must be able to support a minimum weight of 500 kg/m
2
(110 lbs. / feet
2
)
Protection against Radiation
To protect against radiation hazards, follow all federal and municipal requirements.
During exposure, the operator should follow applicable radiation shielding
requirements and remain at least 2,000 mm (78.7’) from the source of the radiation.
Maintain visible contact with the patient and a clear view of indicators such as the
warning lamp and imaging status on the PC.
