Vega DSGH - Page 36

34 DSGH Installation and Operation Guide
Installation
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Customer Earth
Ground and
Ground to Housing
DSG Perforated View
Relay:
- normally open
- common
- normally closed
L1
AC or DC power input
L2
RY NO
RY C
RY NC
Not used in HART
applications
Auxiliary input power
Common
Auxiliary input frequency signal
Current loop output
Interconnecting terminals — GEN2000 with
