72 DSGH Installation and Operation Guide
Diagnostics and repair
Acknowledging diagnostic alarms
Diagnostic alarms turn off when the problem is solved, except these alarms:
• Source wipe due
• Shutter check due
• Standardize due
Perform the procedure to acknowledge them.
Diagnostic alarm messages
Active alarm messages may appear on the Ohmview 2000 menu if the
alarm condition is selected. You can select individual alarm conditions in the
Alarms | Diagnostic Alarm Enable tab.
When a HART device initially connects to the gauge, any conditions in
alarm appear on the screen.
Note: If the relay is set as a diagnostic alarm, you must acknowledge
all diagnostic alarms to reset the relay.
Table 5.3
Diagnostic alarm conditions
Diagnostic check
and Normal/Error
conditions
HART message
Diagnostic description Action
RAM Status –
Pass/Fail
RAM corrupt
RAM memory corruption
occurred and was resolved
internally. Repeated triggering
of this alarm suggests a
hardware problem.
Consult VEGA Field
Service.
Sensor EEPROM
– Pass/Fail
Sensor EEPROM corrupt
A critical memory corruption
occurred on the sensor pre-
amp board EEPROM that may
not be resolved internally.
To check for recurrence,
acknowledge the alarm.
Cycle power to the unit.
If the alarm recurs, there is
a hardware problem.
Perform the procedure to
repair the corrupted
EEPROM on page 4-63.
