12 Menu overview
VEGAPULS 6X • Two-wire 4 … 20 mA/HART
66190-EN-221107
12 Menu overview
12.1 Display and adjustment module
Lock/Unlock adjustment
Menu item Parameter Selection Default setting
Lock/Unlock adjust-
ment
Lock, unlock Released
Setup
Menu item Parameter Selection Default setting
Measurement loop
name
Sensor
Distance unit Distance unit mm, m, in, ft m
Type of medium Type of medium Liquid Liquid
9)
Bulk solid Bulk solid
10)
Application Application - liquid Storage tank, agitator tank, dosing tank,
standpipe, tank/collection basin, plastic
tank (measurement through tank top), mo-
bile plastic tank (IBC), level measurement in
waters,owmeasurementume/overow,
pump station/pump shaft, combined sewer
overow,demonstration
Storage tank
11)
Application - bulk
solid
Silo, bunker, crusher, heap, demonstration Silo
12)
Vessel height Recommended
meas. range, see
chapter " Technical
data"
Distance A (max.
value)
Max. value Max. adjustment
100 % corresponds
to 0,000 m
Distance B (min.
value)
Min. value Min. adjustment
0 % corresponds to
120,000 m
9)
 Plastichornantenna,threadwithintegratedantennasystem,angewith
encapsulated antenna system
10)
Flange with lens antenna
11)
Plastichornantenna,threadwithintegratedantennasystem,angewith
encapsulated antenna system
12)
Flange with lens antenna
