Manual Micro Dispensing Systems MDS 3010A-FA and MDS 3020A-FA
VTK-VS-BA-002 Revision B 17
6. Micro Dispensing Valve MDV 3010A and MDV 3020A
6.1. Technical data MDV 3010A/3020A
Property
Value
Unit/Explanation
Dispensing quantity range
from 9
nl per cycle
Supply air pressure range
0.1 to 7
bar (relative) (0,1 – 73 psi)
Dynamic viscosity of dispense media
Low and middle viscous media (depending on thixotrophy)
Response time
about 1
ms
Accuracy of dispensing quantity
< 1
% (at p, T = const)
This property is strongly
fluid-dependent
Maximum dispensing frequency
450
1/s
Continuous load dispensing frequency
200
1/s
Operating temperature range
10 to 50
°C
Corrosion resistance
all aqueous media, organic solvents, weak acids and
alkaline
Dimensions (basic version)
115 x 39.5 x 10
mm
Weight
220
g
Table 3: Technical data MDV 3010A/3020A
6.2. Valve types/Options
Types:
 MDV 3010A: low viscous, ceramic tappet
 MDV 3020A: low viscous, ceramic tappet
 MDV 3200A: high viscous, ceramic tappet
Optional:
 Nozzle heater
 Nozzle fixing unit
 Fluid box module heating
 Cartridge connectors
6.3. Special features MDV 3010A/MDV 3020A
6.3.1. Normally closed
In static condition the valve is closed. No uncontrolled leaking of dispensing medium.
6.3.2. Quick-Change
The fast adjustment of the nozzle orifice allows a quick change. The exact position of the new
nozzle insert is controlled by reliable electronics.
6.3.3. Null-set dispensing
Dispensing without medium (inflow disconnected) leads to stronger wearing, mainly of the nozzle
insert. This application has to be avoided.
6.3.4. Modularity
All Micro Dispensing Valves are configured modular. Several components can be exchanged
quickly. Therefore repair time and costs are reduced significantly.
