1.3. Machining
All components of Micro Dispensing Valves, control units and heating are manufactured by state-
of-the-art production machines and are carefully monitored by most modern measuring
instruments. The long-term experience of VERMES Microdispensing and its staff dealing with
piezo-based electronic actuators and controllers guarantees highest functionality and product
quality.
All components of the MDS 3000 series are subject to extensive final checks following the
manufacturing; furthermore they undergo a thorough cleaning process.
All finished Micro Dispensing System components are bedded dust-proof and protected against
harmful environmental influences.
1.4. Product line MDS 3000
The Micro Dispensing Systems of the MDS 3000 family are composed of various piezo-based
Micro Dispensing Valves (MDV line), a Micro Dispensing Control Unit (MDC line) and optional
supply units (MDX line).
Figure 1: Micro Dispensing System MDS 3000
To cover a wide range of viscosity VERMES Microdispensing developed three different types of
valves which can be used depending on the viscosity of the media.
MDV 3010A: for low viscous fluids (water-like fluids)
MDV 3020A: for medium viscous fluids (e. g. ink, honey-like fluids)
MDV 3200A: for high viscous fluids (e. g. grease, pastes)
1.5. List of abbreviations
Nozzle unit with fixation
Nozzle adjustment nut with fixation
Micro Dispensing Controller
Micro Dispensing Fluid box
Programmable logic controller
Table 1: Abbreviations
